Kellwood Lighting
Sports stadium LED floodlights from 600W to 1200W, up to 192,000 lumens
About this business
Kellwood Lighting manufactures and supplies the Ashcroft Series, a sports stadium LED floodlight range. The luminaires produce up to 192,000 lumens and are offered in nominal power ratings from 600W to 1200W, with integrated or remote drivers. The company states the range is designed to deliver television broadcast-quality lighting for professional stadiums and is suited to Class 1 sports venues such as football, rugby, hockey and athletics.
The floodlight is built for elevated, exposed locations. It has an IP67-rated driver enclosure for on-board or remote cabinet installation using plug-and-play cabling, and 20 kV surge protection against harsh weather, lightning and electrical supply surges. Its modular, compact design with easy-adjust mounting is intended to minimise bracket loads and simplify aiming on masts or stands, and seven interchangeable optics, including super-narrow and asymmetric beam angles, allow photometric performance to be tailored to different field and mounting layouts.
Published performance data for the series includes 160lm/W luminaire efficacy with the 5050 chip at CRI>70 and 5000K CCT, lumen output of 96,000lm to 192,000lm, and chip lumen maintenance reported as L80B50 ≥111,000 hours at 25°C. Primary conformities are CE (EMC, LVD, RoHS, ErP) and ENEC, and the series carries a 5-year warranty. Kellwood Lighting can be contacted on +44 (0)1387 255816.
Why choose them
- Ashcroft Series stadium floodlights from 600W to 1200W, up to 192,000 lumens
- 160lm/W efficacy with 5050 chip at CRI>70 and 5000K CCT
- IP67 driver enclosure, on-board or remote, with 20 kV surge protection
- Seven optics: 12°, 30°, 45°, 60° symmetric plus F1, F2, F3 asymmetric
- CE (EMC, LVD, RoHS, ErP) and ENEC conformities with a 5-year warranty
Services
Contact this business
Tell us what you need. Sportdoo handles your enquiry and replies to you — your details are never passed on.
Your business? Claim this listing
Free: fix your details and reply to people looking for you.
Frequently asked questions
What is the Ashcroft Series stadium floodlight?
The Ashcroft Series is Kellwood Lighting's sports stadium floodlight range. It produces up to 192,000 lumens, ranges from 600W to 1200W, and is designed for Class 1 sports venues that need TV broadcast-compliant lighting such as football, rugby, hockey and athletics.
What ingress protection and surge protection does it offer?
The Ashcroft Series has an IP67-rated driver enclosure, which can be supplied attached to the floodlight or installed remotely in a cabinet using plug-and-play cabling. It also has 20 kV surge protection against lightning and supply surges.
Which beam angles can I choose?
Seven interchangeable optics are available: four symmetric optics (12°, 30°, 45° and 60°) and three asymmetric optics (F1 38°x100°, F2 14°x108°, F3 27°x110°). Kellwood advises contacting its design team for help choosing the right distribution.
What performance figures are published for the Ashcroft Series?
The luminaire efficacy is 160lm/W with the 5050 chip at CRI>70 and 5000K CCT, giving a lumen output of 96,000lm to 192,000lm. Chip lumen maintenance is reported as L80B50 ≥111,000 hours at 25°C.
What certifications and warranty come with it?
Primary conformities listed are CE (EMC, LVD, RoHS, ErP) and ENEC, and the series carries a 5-year warranty. Kellwood Lighting can be reached on +44 (0)1387 255816 to discuss a project.
